ALIGN Four Blades Main Rotor Head assembly H50145 - T-REX 500
| Product: | |
 | |
| Product: | |
 | |
| Product: | |
 | |
| Package: | |
 | |
| Instructions: | Specification: |
●Following the release of multiple 500 class scale fuselages, we have introduced a highly scale 4-bladed main rotor head. The complete head assembly is constructed of CNC machined high strength alloy metal, and anodized for aesthetically pleasing appearance. The scale detail of this head assembly, when combined with our UH-60 Blackhawk or Hughes fuselages, results in scale quality never before seen in other similar products. Due to the flybarless construction of this rotor head, an electronic flybarless system is required for operation . | ●500 Four-blades main rotor head set x 1 ●500 Four-blades swashplate x 1 ●Ball link x 8 ●Linkage ball B(M2.5x3)(φ4.75x9.77mm) x 4 ●Socket screw(M3x10mm) x 4 ●Washer (φ3xφ10x1mm ) x 4 ●Linkage rod(φ1.96x34mm ) x 4 ●Socket screw(M2.5x12mm) x 12 ●Bearing(φ3xφ6x2.5mm) x 4 ●FMR52ZZ Bearing(φ2xφ5x2.3mm) x 4 ●Washer (φ3xφ4.8x0.3mm ) x 2 ●Socket button head screw(M3x12mm) x 1 ●Socket button head screw(M3x16mm) x 1 ●Washer (φ6.1xφ10.5x0.4mm ) x4 ●Linkage ball B(M2.5x3)(φ4.75x9.77mm) x 4 ●Linkage ball A(M2.5x3.5)(φ4.75x8.18mm) x 4 ●Long linkage ball (M2.5x3)(φ4.75x24.59mm ) x 1 ●Socket screw(M2x5mm) x 4 |
| Type: | |
|---|---|
| Vendor: | |
| SKU: |
H50145T |
| Weight: |
1.0 lb |
Product Spare Parts
Customer Reviews
good seller fast shipper
The package looks without damage from outside but the swash plate upon rotating show tilt. Tried to fix with simple pressing using plier but no success.
Great product!! Looks great on my Heli
ALIGN Four Blades Main Rotor Head assembly H50145 - T-REX 500
Beautifully machined parts and freak exploded view for assembly. All bolt left loose for easy application of loctite. Great performance, no phasing.
Just bought a four blade rotor head for a trex 500 hope it will work on a 450
Align quality throughout
Have used this in many scale conversions. Well engineered and flies great!
Beautiful part
The service is awesome I'll buy from them again over and over thanks
